Our tools and means:
Electrical, Automation and Instrumentation drawings with SEE ELECTRICAL
LV & HV cables sizing
LV Components and Electrical cabinet set up,
Sizing of cooled & refrigerated electrical cabinets
Thermal and pressure calculation notes
Steel frame calculation
ISO and PID drawings
SIL Loop & Intrinsic safety
Safety light curtains
DG SKID adress international EPCs and Utilities:
Intervention at worldwide Scale
We speak English, Spanish and French
We know the international standards and regulations framing process industries such as FDA, ATEX, NEC, API, NFPA.
Our close collaboration with the major certifying bodies ensures conformity of the installation according to the industry standard.
Because the industrial products are becoming commodities, the process expertise and service are the added value.
We have sumed up the DG SKID approach under this statement for the best interest of our customers, the sustainability of our activities and the development of our people.
It's with this spirit that we will take into consideration your requests and inquiries and animate the roll out of DG SKID.
This for all our customers in all countries.
The enhancement of technical expertise, the adaptation capacity & thinking of our employees is a pillar of our entrepreneurial project.
The HR and recruitment policies are a strong driver for our roll out which will make the difference between companies of today and tomorrow.
We are living those values as managers but also as human beings.
We are introducing our company to collaborators and partners as a collaborative place where each and every individual must enjoy what he/she is doing and what he has been hired for.
We wish that this message will sweat in the exchanges that you will have with all DG SKID representatives.
DG SKID has got the ISO 9001, ISO 45001 and MASE. certifications.
DG SKID has a volunteer approach towards any quality certificates required by the industry or customer we address.
This is the best interest of our employees and customer.
Our key applications and recent business cases:
PLC & HMI programming according to the CFR21 part 11
Equipment meeting FDA, ATEX & NEC, API & NFPA requirements
Monitoring of pressure, temperature and flow signal,
Syncronous and asyncronous Variable speed drives
AC motors : constant & quadratic torque
Generator and alternator
Application with several source of power supply
Installation of derated components due to altitude or temperature
Installation in hazardous area
Projects complying with IEC, NEMA, CSA and UL/C-UL standards
Profibus, Profinet, Modbus RTU & TCP fieldbus
PLC & HMI SIEMENS S7 (STEP7, WinCC/ TIA Portal)
S7-200 -1200 -300-400 range
Intrinsic Safety : MTL & SIEMENS Range
Reactor, mixer, piping with double envelop
Fluid Transfer Skid, heat exchange platform, pumping & proportionning & vacuuming Skids
Regulation & Control loop : temperature, flow, pressure
Storing tanks, silos and sphere
